S Helical Worm Gear Reducer
S Helical Worm Gear Reducer
Description
S Series Helical–Worm Gear Reducer integrates a worm gear/worm pair with a precision helical gear stage, forming a highly efficient two-stage transmission where the input and output shafts intersect spatially. The gears and worm are carburized and quenched to a hardness of HRC 58–62, with a hardened layer depth of 0.2–2 mm for excellent wear resistance and long service life.
The worm wheel is cast from bronze using a centrifugal casting process to achieve superior strength and uniformity.
Featuring compact construction, stable torque output, and multi-installation flexibility, the S Series is widely used across demanding industrial sectors such as petroleum, metallurgy, mining, lifting, transportation, cement, construction, chemical processing, textiles, dyeing, pharmaceuticals, food processing, and environmental engineering.
Highlights
- High Reduction Ratios
Two-stage reduction (helical gear + worm gear) delivers smooth transmission with large ratio availability. - Innovative Structure
The combination of a worm gear/worm set and a helical gear creates a compact reducer with non-parallel, non-intersecting input and output shafts. - High Efficiency & Lightweight Design
Optimized tooth geometry, modular configuration, compact housing, and reduced weight ensure higher efficiency and appealing industrial aesthetics. - Low Noise & Low Vibration
Fine ratio grading and precision-machined gears significantly reduce vibration and operational noise.
Technical Parameters
| Item | Specification |
|---|---|
| Output Torque | 200–50,000 Nm |
| Motor Power Range | 0.12–200 kW |
| Output Speed | 0.1–522 r/min |
| Output Types | Flange + Solid Shaft / Foot Mount + Solid Shaft / Flange + Hollow Shaft / Foot Mount + Hollow Shaft / Torque Arm + Hollow Shaft |
| Hollow Shaft Options | Single Keyway / Involute Splined / Shrink Disc Locking |
| Output Directions | A Direction / B Direction / A + B |
| Gear Material Hardness | Carburized & quenched HRC 58–62 (0.2–2 mm layer) |
| Worm Wheel Material | centrifugal casting |
Product Features
- Input and output shafts arranged in a spatial offset, maximizing housing utilization, enabling a compact, high-strength layout.
- Hardened gear surfaces deliver high torque density, excellent load-carrying capability, and long operational life.
- Precision-ground helical and worm gears ensure smooth engagement, reduced backlash, and low operating noise.
- Integrated cast-iron housing provides excellent structural rigidity, enhancing shaft strength and extending bearing life.
Application
The S Series Helical–Worm Gear Reducer is engineered for medium-to-heavy duty industrial applications requiring compact dimensions, high reduction ratios, and stable, quiet operation. Typical applications include:
- Petroleum & Petrochemical Equipment
- Metallurgy and Steel Processing Lines
- Mining and Material Handling Systems
- Cranes, Hoists, and Lifting Machinery
- Transport Conveyors and Logistics Equipment
- Cement, Construction, and Building Machinery
- Chemical Processing and Environmental Systems
- Textile, Dyeing, and Printing Machines
- Pharmaceutical and Food Processing Equipment
