HK Series Worm Gear Screw Jacks are heavy-duty linear motion actuators that combine a worm-gear reducer with a trapezoidal (T-type) screw to achieve lifting, lowering, pushing, pulling, and precise positioning. The series supports a wide load range from 2T to 100T, making it suitable for industrial equipment requiring reliable mechanical lifting with high stability and long service life.

The system provides multiple structure types including translating screw (Type 1) and rotating screw (Type 2), along with various assembly orientations, screw-end configurations, anti-rotation protection, and protective cover options. Each unit can be customized for stroke, speed ratios, installation direction, and environment-specific protection requirements.

Feature

• Load capacity from 2T to 100T
• Worm-gear transmission with inherent self-locking capability
• Type 1 (translating screw) / Type 2 (rotating screw) structures
• Multiple screw-end types: cylindrical, flange, threaded, flat-head
• Upward or downward assembly direction (Type A / Type B)
• Anti-rotation protection options (F-key, square tube guide)
• Protective cover options: Z steel tube (passive side), X telescopic tube (active side), Q double protection
• Customizable lifting stroke
• High reliability and long service life
• Suitable for independent operation or synchronized multi-jack systems

HK Series Parameters Table (English Version)

HK Primary Selection Form

Highlights

• High load-bearing capability and resistance to impact loads
• Excellent mechanical efficiency and smooth motion
• Long operational lifespan under continuous duty
• Customizable configurations for diverse industrial equipment
• Supports synchronized multi-jack linkage through mechanical or electric systems
• Minimal maintenance thanks to optimized lubrication design

Application

• Industrial lifting platforms and heavy mechanical actuators
• Steel mills, mining equipment, and large processing lines
• Stage lifting systems and theater platforms
• Material handling and automated logistics systems
• Machinery requiring stable vertical positioning
• Solar tracking systems and renewable energy equipment
• Adjustable fixtures, presses, and tooling platforms
• Construction equipment and lifting mechanisms
